| EGCS | General description | Name of unit | EG-100-SI (Inlet line) |
|---|---|---|---|
| EG-100-SO (Outlet line) | |||
| External dimension | 600 (W) 脳 400 (D) 脳 1700 (H) mm except for | ||
| Measurement condition for EG-100-SI | Sample condition | 0.1 MPa 锝� 0.4 MPa 3 L/min for supply | |
| Fresh water line*1 | 0.1 MPa 锝� 0.7 MPa 3 L/min for supply | ||
| Measurement condition for EG-100-SO | Sample condition | 0 锝� 0.1 MPa 3 L/min for supply | |
| Fresh water line*1 | 0.1 MPa 锝� 0.7 MPa 3 L/min for supply | ||
| Connection | Sample in line | JIS10K25A | |
| Sample out line | JIS5K25A | ||
| Fresh water line | JIS5K15A | ||
| Measurement item | pH speci铿乧ation | 1 锝� 11 pH (with temperature compensation) | |
| PAH speci铿乧ation | select a range from 0 锝� 50/500/5000 渭g/L | ||
| Turbidity speci铿乧ation | 0 锝� 500 FNU | ||
| Temperature speci铿乧ation | 0 鈩冿綖 100 鈩� (sample temperature 0 锝� 40 鈩�) | ||
| EGR | General description | Name of unit | EG-100-N |
| External dimension | 600 (W) 脳 400 (D) 脳 1150 (H) mm except for | ||
| Measurement condition | Sample condition | 0 锝� 0.1 MPa 3 L/min for supply | |
| Fresh water line*1 | 0.1 MPa 锝� 0.7 MPa 3 L/min for supply | ||
| Connection | Sample water line | Rc 1/2 | |
| Fresh water line | Rc 3/8 | ||
| Measurement item | pH speci铿乧ation | 1 锝� 11 pH (with temperature compensation) | |
| PAH speci铿乧ation | select a range from 0 锝� 50/500/5000 渭g/L | ||
| Turbidity speci铿乧ation | 0 锝� 500 FNU | ||
| Temperature speci铿乧ation | 0 鈩冿綖 100 鈩� (sample temperature 0 锝� 50 鈩�) |
*1 Before connecting fresh water supply to the cabinet, confirm flushing the pipe line for removing rust and piping scale in advance.
